Temperature Control Internal Lithium Ion Battery Short Circuit Test Machine
Applications:
This Temperature Control Internal Lithium Ion Battery Short Circuit Test Machine is a comprehensive test system that applied for Lithium Battery as well as battery pack & battery cell safety test. This battery tester is designed and manufactured in compliance with Japan Industrial Standard as JISC 8714:2007 Clause 5.5 & IEC 62133-2017 Clause.
Related Standard Test Requirements:
IEC62133-2017
Features:
1.Fully Computerized control method and comprehensive battery test as 13KN crush, deformation, voltage, temperature acquisition, and temperature control;
2.Servo motor with ball screw & explosion-proof cabinet are introduced for this battery system.
3.Internal chamber employs mirror stainless steel with viewing window, light, air blower, universal wheel on the bottom
that easy to mobile;
4.Software system control make an availability to set all operational parameters in an direct way. Designed with
attractive appearance & real-time monitoring that easy to supervise the test process.
Temperature Chamber Technical Parameters:
Model | BE-6045W |
Temperature Range | -10℃ ~ +80℃(Controllable) |
Temperature Rising Rate | Ave.3℃/min(-10℃ to 80℃,Nonlinear No-load) |
Temperature Cooling Rate | Ave.1℃/min(80℃ to 10℃,Nonlinear No-load) |
Inner Chamber Dimension | W600 X H750 X D500 MM |
External Chamber Dimension | W1170 X H1850 X D1020MM |
Inner Chamber Material | Stainless steel with mirror-finish, bottom reinforcement |
External Chamber Material | Cold-Rolled Steel with paint-baked coating |
Observation Window | The single-opening door is accompanied by a 3-layer vacuum large glass observation window (W430mm x H 580mm); The door frame is equipped with electric heating (automatic adjustment) anti-frost, anti-condensation device; so that you can clearly observe the Test status of the test sample in the box through the observation window at any time. |
Internal Short Circuit Technical Parameters
Max. Loading | 200KG |
Resolution | 1/10000 |
Force Accuracy | ≤0.5% |
Displacement resolution | 1/1000 |
Accuracy of displacement | ≤0.5% |
Speed Range | 0.01-5MM/S |
Effective Range | 0 ~ 200mm |
Max. Test Area | 300X300MM (Can be customized) |
Voltage Range | 0—60V |
Voltage Resolution | 5mV |
Voltage Acquisition Frequency | 100HZ |
Control System | Servo motor + Servo control system |
Safety Protection | Explosion-proof pressure relief device, smoke exhaust device, fire extinguishing system, electronic door lock system, safety stop switch |


Company Information



Guangdong Bell Experiment Equipment Co., Ltd is located in Dong Cheng District, Dong Guan City Guangdong Province, with register capital of RMB16.8 million. The factory covers an areas of 20,000 square meters with a building area of over 12,000 square meters. We are a high-tech enterprise specialized in manufacturing Battery Safety Test Equipment, Environmental Test Equipment and Mechanical Test Equipment, with more than 10 years’ experience of R&D.
Bell boost a team that consists of more than 120 employees and 60 of them with college educated background and 15 of them with senior engineer qualification. Enable us to provide excellent equipment and service to satisfy various customers, especially the customized non-standard equipment. Our experienced and well trained engineer team provides installation and after-sales service, making Bell to be the leading manufacturer of test equipment in China.
Packaging & Shipping

Packing:
1. Fully packed with PE film;
2. Wooden box;
3. Machine is fastened to the corners of the containers;
4. If export to European countries, the wooden box will be fumigated;
5. Customized package is available.


Certifications

FAQ:
1. Are a manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
-Yes, we are manufacturer of Temperature Control Internal Lithium Ion Battery Short Circuit Test Machine. Every machine from our factory has a 12 months product warranty. If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What’s the delivery term?
-If there is no stock, normally, the delivery time is 15-25 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
-Yes, of course. We can not only offer standard machines, but also customized
machines according to your requirements. And we can also put your logo on the machine
4. what about the products' quality?
-Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency.
5.what about the packing of equipment?
-We use Standard Export Plywood Case to Protect it from rust during the long time shipping with the plastic film and protect its corners with the foam.
