Horizontal Vertical Battery Crush Nail Penetration Test Devices

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Contact us

Bell Experiment Equipment Co., Ltd.
[China]

Address
No. 11, Wusong 1st street, Yuwu, East City District Dongguan Guangdong
Phone
0086-0769-23280911
Contact name
Eric King

Quick Information

  • Brand Name: DGBELL
  • Place of Origin: China
  • Model Number : BE-6047AP
  • :

Description

Horizontal Battery Crush Nail Penetration Test Devices

Product Description

Horizontal Battery Crush Nail Penetration Test Devices

Relevant standards requirement:

1. Test object: Battery storage pack or system.

2. Crush according to the following conditions

(1) Crush plate:half cylinder with radius 75mm,length of the plate should be larger than the crushed battery size but shorter than 1m;

(2) Crush Direction: X and Y direction (car driving direction called X axis, another horizontal direction perpendicular to car driving direction called Y axis). To ensure the safety of test operation, tests can be performed on two test objects separately.

(3) Crush level: Stop the crush when the crush force reached 100KN or the crush deformed by 30% of the total size of the crush direction for the battery pack, remain for 10mins.

3. After testing, observe for 1h under the testing temperature.



Safety device:

1. Flame resistance and explosion-proof design for the test area.

2. Rust-proof and anti-corrosion design for the test area.

3. Emergency stop button.

4. Over pressure protection

5. Crush limit protection device.

6. Water-proof for the test area.

7. Other safety design.

Product specification:

Model

BE-6047AP-20T

BE-6047AP-50T

BE-6047AP-100T

Pressure (T)

20

50

100

Structure

Horizontal

Horizontal

Horizontal

Crush Mode

Horizontal

Horizontal

Horizontal



Performance parameters:

Drive Mode

Electro-hydraulic servo

Chamber

Independent horizontal structure and control system

Test Space

W2500 X D2000 X H1000mm (can be customized)

Overall Dimension

W8500 X D2500 X H2400mm

Energy Saving Design

Adopt dual hydraulic cylinder driving,  main-subsidiary hydraulic cylinder design. Maximized saving space and reduce the total power configuration of the equipment.

Power Supply

AC380V 50HZ

Crush Speed

1~400mm/min (Adjustable)

Nail Penetration Speed

1~40mm/s (Adjustable)

Test Condition

The variable of force, displacement, speed, time, auxiliary voltage, auxiliary temperature (.etc) can be used as control variable in nail penetration and crush tests.

Control Mode

MCU+PC combined control mode, remote control operation to ensure the safety of testing.

Running Mode

Available for Programming Mode and Constant Mode

Crush Accuracy

≤0.5%(FSR)

Nail Penetration Accuracy

≤1%(FSR)

Crush Deformation

0~100% multistage setting, multi-layer crush deformation loading available.

Crush Fixture

Arc crush plate ( Radius 75mm), available for different fixtures according to different test standards.

Data Acquisition Module

Independent remote collection and isolation, Multiplex voltage, temperature, current acquisition channel, ensure the data correctly .

Safety Alarm Device

Electrical leakage, over voltage, overload and over temperature, over current protection, abnormal sound and light alarm, smoke alarm lamp, etc

 Horizontal Battery Crush Nail Penetration Test DevicesHorizontal Battery Crush Nail Penetration Test Devices

Company Information

 Horizontal Battery Crush Nail Penetration Test DevicesHorizontal Battery Crush Nail Penetration Test Devices



DongGuan Bell Experiment Equipment Co., Ltd is located in Dong Cheng District, Dong Guan City Guangdong Province, with register capital of RMB16.8 million. The factory covers an areas of 20,000 square meters with a building area of over 12,000 square meters. We are a high-tech enterprise specialized in manufacturing Battery Safety Test Equipment, Environmental Test Equipment and Mechanical Test Equipment, with more than 10 years’ experience of R&D.



Bell boost a team that consists of more than 120 employees and 60 of them with college educated background and 15 of them with senior engineer qualification. Enable us to provide excellent equipment and service to satisfy various customers, especially the customized non-standard equipment. Our experienced and well trained engineer team provides installation and after-sales service, making Bell to be the leading manufacturer of test equipment in China.



Packaging & Shipping

 Horizontal Battery Crush Nail Penetration Test Devices

Packing:

1.    Fully packed with PE film;

2.    Wooden box;

3.    Machine is fastened to the corners of the containers;

4.    If export to European countries, the wooden box will be fumigated;

5.    Customized package is available.



Horizontal Battery Crush Nail Penetration Test Devices

 Horizontal Battery Crush Nail Penetration Test Devices

Certifications

 Horizontal Battery Crush Nail Penetration Test Devices

FAQ:



1. Are a manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?

-Yes, we are manufacturer of Horizontal Battery Crush Nail Penetration Test Devices. Every machine from our factory has a 12 months product warranty.If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.



2. What’s the delivery term?

-If there is no stock, normally, the delivery time is 15-25 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.



3.  Do you accept customization service? Can I have my logo on the machine?

-Yes, of course. We can not only offer standard machines, but also customized

machines according to your requirements. And we can also put your logo on the machine



4.  what about the products' quality?

-Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency.



5.what about the packing of equipment?

-We use Standard Export Plywood Case to Protect it from rust during the long time shipping with the plastic film and protect its corners with the foam.



Horizontal Battery Crush Nail Penetration Test Devices



Price

  • Delivery Port : ShenzhenGuangzhou

Packaging & Delivery

  • Packing :StandardExportingPolyWoodBox
  • Packaging Size : 8500 x 2500 x 2400
  • Package Weight : 4000
  • Delivery Lead Time : 30
  • Supply Ability : 200
